Advantech IPPC-9151G / IPPC-9171G

15"XGA / 17"SXGA TFT LED LCD Intel®Core™ i7 / i5 / i3 Celeron® Industrial Touch Panel PC with 1 x PCIe Slot

Advantech IPPC-9151G / IPPC-9171G
  • egenskaberegenskaber
  • beskrivelsebeskrivelse
  • yderligere informationyderligere information
  • PDFPDF
  • Intel® Core™ i7/i5/i3 Celeron® μFC-PGA988 processor with Intel® QM67 chipset
  • 15" XGA/17" SXGA LED backlight LCD with low power consumption
  • Front access USB connector
  • Supports 1 xPCIe x1 or 4 (Gen2) (PCI optional)
  • Heavy-duty stainless steel chassis with aluminum front panel
  • Strengthened glass protects the front panel from shock damage and s IP65 compliant
  • Supports dual display of HDMI, LVDS, VGA
  • Supports 1 x 2.5" SATA II or SATA III HDD and 1 x CFast
  • Hard anodic coating to prevent panel abrasion and acid corrosion
  • Supports embedded software APLs and Utilities
IPPC-9151G/IPPC-9171G is a fully functional computer system with front USB access, with Intel® mobile Core i7-2710QE 2.1GHz/Core i5-2510E 2.5 GHz/Core i3-2330E 2.2 GHz /Celeron® B810 1.6 GHz processors up to 6 MB L3 cache and DDR3 SO-DIMM 1066/1333 up to 8 GB and a resolution up to 1024 x 768 to meet the demands of today´s high-end industrial software. The IPPC-9151G/IPPC-9171G is a rugged unit with an aluminum panel,15"/17" TFT LCD with LED backlight, a stainless steel structure and a Pcie slot. The IPPC-9151G/9171G is rugged enough to handle the toughest industrial operating environments. With optional mounting accessories, from panels to racks, it can be mounted anywhere.
ProdGrafik

Specifications


    General

      BIOS
      AMI EFI 64 Mbit SPI

      Certification
      BSMI, CCC, CE, FCC, UL

      Cooling System
      2 x 10.1 CFM fans w/50,000 hrs MTBF

      Dimensions (W x H x D)
      IPPC-9151G:
      428 x 310 x 96.5 mm (16.35" x 12.2" x 3.79")
      IPPC-9171G:
      482 x 354.8 x 98 mm (18.98" x 13.97" x 3.86")

      Disk Drive Bay
      Supports 1 x 2.5" SATA II or SATA III HDD

      Enclosure
      Stainless steel back case, 10 mm aluminum front panel

      Mounting
      Panel, rack

      Power Input
      100~240 V AC @ 4A 50~60hz

      Power Supply
      180 W, MTBF: 100,000 hrs

      Weight (Gross)
      IPPC-9151G:    10.52 Kg (23.19 Ibs)
      IPPC-9171G:    14 Kg (30.86 lbs)

      OS Support
      Win XP, Win 7



    System Hardware

      CPU
      Supports uFC-PGA988 Intel® mobile Core i7-2710QE 2.1 GHz/Core i5-2510E 2.5 GHz/Core i3-2330E 2.2 GHz/Celeron® B810 1. 6GHz processor

      Chipset
      Intel® 6 series chipset (QM67)

      Audio Ports
      Mic-in, Line-out, Line-in

      Expansion Slots
      Supports 1 x PCIe x1 or x4 (PCI optional)

      PS/2
      1 x keyboard and 1 x mouse

      LAN
      2 x 10/100/1000 Mbps

      Memory
      2 x 204 pin DDR3 1066/1333 SODIMM sockets supports up to 8GB (2 x 4GB)

      Cfast
      1 x CFast slot

      I/Os
      1 x VGA; 1 x HDMI; 5 x USB 2.0 (one at front);
      4 x RS-232



    LCD Display

      LCD Display Type
      IPPC-9151G:    XGA TFT LCD with LED Backlight
      IPPC-9171G:    SXGA TFT LCD with LED Backlight

      Display Size
      IPPC-9151G:    15";
      IPPC-9171G:    17"

      Max. Resolution
      IPPC-9151G:    1024 x 768;
      IPPC-9171G:    1280 x 1024

      Max. Colors
      IPPC-9151G:    16.2M or 256K Color
      IPPC-9171G:    16.7M colors (RGB 6-bits +Hi-FRC data)

      Viewing Angle (H/V°)
      IPPC-9151G:    160/140;
      IPPC-9171G:    170/160

      Luminance
      IPPC-9151G:    350 cd/m²;
      IPPC-9171G:    380 cd/m²

      Backlight Life
      50,000hrs

      Contrast Ratio
      IPPC-9151G:    700:1;
      IPPC-9171G:    400:1



    Touchscreen

      Lifespan
      36 million with a silicone rubber of R8 finger, writing rate is by 250g at 2 times/s

      Light Transmission
      > 80%

      Type
      Analog resistive (5-wire)



    Environment

      Humidity
      5 ~ 85% @ 40°C (non-condensing)

      Ingress Protection
      Front panel: IP65

      Operating Temperature
      0 ~ 50°C (32 ~ 122°F)

      Storage Temperature
      -20 ~ 60°C (-4 ~ 140°F)

      Vibration Protection
      5 ~ 500 Hz, 1 G RMS random vibration





Ordering Information

  Available Modules
  IPPC-9151G-R1AE   15" XGA Intel® Core™ i7/i5/i3 Celeron with TS
  IPPC-9171G-R1AE   17" SXGA Intel® Core™ i7/i5/i3 Celeron with TS
