RARITAN Paragon II - UMT832S
Product is End of Life : 2020-11-20
Expanion Ports for UMT832M
- Powerful BIOS-level access and full keyboard and mouse control of Windows, SUN and USB servers
- High performance analog switching provides extremely high video quality
- Stacking allows expansion of each switch to attach up to 128 devices per switch with a single cable.
- Simplifies cabling between tiers by replacing pass through cables with a single expansion cable saving up to 32 cables per switch.
- Stacking allows a reduction in the number of units deployed by 33% saving initial costs, rack space and HVAC costs.
- Highly scaleable architecture allows for connection of up to 10,000 attached devices in a single logical deployment.
- Leverages Raritans Cat5 simplicity technology allowing any standard UTP cables to be used
- Optional IP Access extends the typical distance between Paragon components allowing users access from anywhere
- Provides a single, consolidated view and control of Raritan Remote Power Control Units connected to Paragon II
- GUI software simplifies management and monitoring of data center by consolidating administration of attached equipment.
- Supports firmware upgrading and completions of installs over the network saving time and money.
- Allows connection of multiple disparate servers such as Windows, SUN, Compaq, HP and UNIX-based servers. Also allows serial devices to be connected via Raritans AUATC adaptors.
- Backward compatible with existing Paragon equipment
- Very small form-factor saves expensive rack space and minimizes electrical consumption by lowering HVAC provisioning needs.
- Integrated power supply ensures proper power provision and system reliability.
The UMT832S stacking unit has 32 expansion ports for stacking with the UMT832M unit. By adding the cost-effective, space-saving UM832S, you can easily add up to 128 non-blocked ports per switch with 90% less cable than traditional cascading.
With the UM832S, you eliminate the burden of multiple cables between cascading levels, reduce Total Cost of Ownership (TCO) by more than 30% and save one-third on rack space required and HVAC resources.
P2-UMT1664M
- Description
- 16 users x 64 server ports, expansion slot, stacking port, network port
Dimensions (WxDxH)
- 17.32" x 11.41" x 3.5";
440 x 290 x 89mm
Weight
- 12.52 lbs;
5.68 kg
Power
- 100V/240V
50/60Hz 0.6A
P2-UMT832M
- Description
- 8 users x 32 server ports, expansion slot, stacking port, network port
Dimensions (WxDxH)
- 17.32" x 11.41" x 1.75";
440 x 290 x 44mm
Weight
- 9.83 lbs;
4.46 kg
Power
- 100V/240V
50/60Hz 0.6A
P2-UMT442
- Description
- 4 users x 42 server ports, expansion slot, network port
Dimensions (WxDxH)
- 17.32" x 11.41" x 1.75";
440 x 290 x 44mm
Weight
- 10.13 lbs;
4.59 kg
Power
- 100V/240V
50/60Hz 0.6A
P2-UMT242
- Description
- 2 users x 42 server ports, network port
Dimensions (WxDxH)
- 17.32" x 11.41" x 1.75";
440 x 290 x 44mm
Weight
- 10.03 lbs;
4.54 kg
Power
- 100V/240V
50/60Hz 0.6A
Paragon II Stacking Units
P2-UMT1664S
- Description
- 64 expansion server ports for stacking with P2-UMT1664M unit
Dimensions (WxDxH)
- 17.32" x 11.41" x 3.5";
290 x 440 x 89mm
Weight
- 11.99 lbs;
5.44 kg
Power
- 100V/240V
50/60Hz 0.6A
P2-UMT832S
- Description
- 32 expansion server ports for stacking with P2-UMT832M unit
Dimensions (WxDxH)
- 17.32" x 11.41" x 1.75";
290 x 440 x 44mm
Weight
- 8.99 lbs;
4.08 kg
Power
- 100V/240V
50/60Hz 0.6A
Produkt Family | Part Number | Class | KVM Ports | Lokal User | Cabeling | Max Tiering | Max Distance | Cables Included | Additional Features |
expreZo Ezswitch | EZ-108 | Desktop | 8 | 1 | Coax | 1024 | 10 ft | Yes | Economical analog KVM switch |
expreZo Ezswitch | EZ-116 | Desktop | 16 | 1 | Coax | 1024 | 10 ft | Yes | Economical analog KVM switch |
MasterConsole CAT | MCCAT116 | Enterprise | 16 | 1 | Cat5 | 256 | 150 ft | No | |
MasterConsole CAT | MCCAT18 | Enterprise | 8 | 1 | Cat5 | 256 | 150 ft | No | |
MasterConsole CAT | MCCAT216 | Enterprise | 16 | 2 | Cat5 | 256 | 150 ft | No | Optional 2nd local user |
MasterConsole CAT | MCCAT28 | Enterprise | 8 | 2 | Cat5 | 256 | 150 ft | No | Optional 2nd local user |
Paragon II | P2-UMT1664M | Enterprise | 64 | 16 | Cat5 | 2048 | 1000 ft | No | Serial via CIM, remote power control, Paragon Manager |
Paragon II | P2-UMT1664S | Enterprise | 64 | 16 | Cat5 | 2048 | 1000 ft | No | Stacking unit, serial via CIM, remote power control, Paragon Manager |
Paragon II | P2-UMT242 | Enterprise | 42 | 2 | Cat5 | 2048 | 1000 ft | No | Serial via CIM, remote power control, Paragon Manager |
Paragon II | P2-UMT442 | Enterprise | 42 | 4 | Cat5 | 2048 | 1000 ft | No | Serial via CIM, remote power control, Paragon Manager |
Paragon II | P2-UMT832M | Enterprise | 32 | 8 | Cat5 | 2048 | 1000 ft | No | Serial via CIM, remote power control, Paragon Manager |
Paragon II | P2-UMT832S | Enterprise | 32 | 8 | Cat5 | 2048 | 1000 ft | No | Stacking unit, serial via CIM, remote power control, Paragon Manager |
TM CAT LCD KVM Switch | TMCAT17216 | Enterprise | 16 | 2 | Cat5 | 256 | 150 ft | No | Integrated LCD drawer and KVM switch |
TM CAT LCD KVM Switch | TMCAT1728 | Enterprise | 8 | 2 | Cat5 | 256 | 150 ft | No | Integrated LCD drawer and KVM switch |
