Raritan MasterConsole Digital LED

prodgraf


17’’ LED-Backlit Console Drawer and Integrated KVM Switch With Analog/Digital Video and Stereo Audio



egenskaber


beskrivelse

Raritan’s MasterConsole® Digital with integrated 17” LED Console Drawer (MCD-LED) is a digital KVM switch and console drawer combination for small to midsized businesses. This advanced combination brings you KVM ports for 8 and 16 servers and can be cascaded 2 levels to support up to 512 connections at distances up to 100 feet (30 meters). The flexible video interface supports both Analog — VGA and Digital — DVI, HDMI and DisplayPort with a maximum HD video resolution up to 1920x1080. The MCD-LED with its convenient space saving design simply connects to multiple computers with the use of standard Category 5/6/6e cables. MCD-LED provides at-the-rack access with a friendly user interface and convenient hotkeys to quickly access connected computers. It is ideal for performing system maintenance, administration, running applications, and troubleshooting.


Scalability and Cascading

Control 8 or 16 servers directly from the MCD-LED switch, or access up to 512 servers by cascading with Raritan’s MCD-232 Cat5 KVM switches.


Space Saving Design

The 1U modular design takes up to 85% less space than a full sized keyboard, monitor, and mouse.


High Resolution LCD Display

Supports 1920x1080 video resolution at 150 feet.


Simple Installation

Plug-and-play installation, auto-configuration, and easy-to-use onscreen displays allow for easily install of the MCD-LED at the rack.


Multi-Language Support

Multi-language keyboard support for US English, UK English, German, French, Spanish, Italian, Korean, Chinese and Japanese.


Password Authentication

Support for one program administrator and up to 127 user profiles for secure and reliable access and simple profile management.






ProdGrafik

yderligere information


CAT5 ANALOG/DIGITAL KVM SWITCH FOR SMALL TO MIDSIZED IT ENVIRONMENTS

Employing state-of-the-art technologies in a compact device, Raritan’s MasterConsole Digital KVM switch (MCD) and 17’’ LED Console Drawer with integrated KVM switch (MCD-LED) provides reliability, ease of use, and convenience that you need in your data center, lab or server room.

The MCD supports the highest HD video resolution of up to 1920 x 1080 via standard Category 5/6/6e. The digital video interface supports both Analog — VGA and Digital — DVI, HDMI and DisplayPort. Stereo audio is also supported by using VGA combo cables or Raritan’s HDMI CIMs.

Building upon Raritan’s history of success with KVM switches, the MasterConsole Digital Series is ideal for performing system maintenance, administration, running applications, and troubleshooting.


CONSOLIDATED ACCESS AND CONTROL OF MULTIPLE SERVERS

The MasterConsole Digital Series efficiently consolidates access and control of multiple servers for one or two users. Models are available for KVM connections to 8, 16, or 32 servers.


CASCADE TO ACCESS AND CONTROL UP TO 1024 COMPUTERS

Using standard Category 5/6/6e unshielded twisted-pair (UTP) cables, MasterConsole Digital Series can be cascaded two levels to access up to 1024 computers.


POWERFUL LCD KVM DRAWER FUNCTIONALITY

With a touchpad mouse, simple on-screen user interface and automatic screen power off, the MCD-LED combination LCD Drawer and KVM switch provides complete system management in an intuitive, simple device. Providing an enhanced visual display with 300 nit brightness, and a typical 650:1 contrast ratio, these switches are an investment in high-performing, user-friendly management of your server environment.


A SINGLE SWITCH FOR DIGITAL AND ANALOG VIDEO

MasterConsole Digital switches and consoles support the latest digital video formats (DVI, HDMI and DisplayPort), as well as servers with analog VGA video. In a single switch! Connect to both new and legacy servers with the MasterConsole Digital CIMs and VGA CIM cables. Stereo audio is available for servers with VGA and HDMI video.


EASIER AND MORE INTUITIVE OPERATION

Operation is easier than ever with intuitive, user-friendly features, including:


INDUSTRY LEADING SCALABILITY AND PERFORMANCE

Designed to provide maximum flexibility and versatility:




MASTERCONSOLE DIGTAL CONSOLE DRAWER KVM SWITCH (MCD-LED) SPECIFICATIONS

Models Description Dimension
(L x W x H)
Weight Maximum Input Power Rating/Power Consumption
MCD-LED17108 1 User, 8 Ports, 256 Managed Servers (Cascaded), 1920 x 1080@60Hz (DVI) Video Resolution,
> 300,000 Hours MTBF
562.71 x 484.7 x 41.5mm 11.15kg AC100-240V, 1.5A;
DC12V/5.42A (65W)
MCD-LED17116 1 User, 16 Ports, 512 Managed Servers (Cascaded), 1920 x 1080@60Hz (DVI) Video Resolution,
> 300,000 Hours MTBF
562.71 x 484.7 x 41.5mm 12kg AC100-240V, 1.5A;
DC12V/5.42A (65W)



MASTERCONSOLE DIGTAL CONSOLE DRAWER LCD (MCD-LED) SPECIFICATIONS

Models Console Drawer Description Supported Colors Brightness Contrast Ratio
MCD-LED17108 17.3"TFT LCD with LED backlight unit,
0.1989 (H) x 0.1989 (V) mm pixel pitch,
1920x1080@60Hz (Full HD 1080P) max resolution,
15,000 Hours MTBF
262,144 300 Nits 650:1
MCD-LED17116 17.3"TFT LCD with LED backlight unit,
0.1989 (H) x 0.1989 (V) mm pixel pitch,
1920x1080@60Hz (Full HD 1080P) max resolution,
15,000 Hours MTBF
262,144 300 Nits 650:1



PDF

PDF beskrivelse Raritan MasterConsole Digital LED Datasheet (780.4 kB)

PDF beskrivelse Raritan MasterConsole Digital LED Datasheet (ger) (783.0 kB)

PDF beskrivelse Raritan MasterConsole Digital LED Features Datasheet (70.0 kB)
